Chapter 5 - Module System Descriptions
78 Adept Python Modules User’s Guide, Rev. E
Two-Axis Configuration Drawings
The drawings in this section show the available two-axis configurations.
D Configuration
In the D configuration, the second axis is mounted in a fixed position on the first-axis'
slide, so that the second axis' slide is opposite the work surface and moves in a horizontal
motion.
Available in the following configurations:
• D1200
• D2300
Figure 5-13. D1200 System with Optional Mounting Feet
X-Axis
Motion
Y-Axis
Motion
Flyover Type
Cable Harness
