Chapter 8 - Power Distribution Unit
126 Adept Python Modules User’s Guide, Rev. E
8.6 PDU3 Mounting Brackets
The PDU3 can be mounted using the supplied mounting brackets, see the following
figure. For dimensions of the mounting brackets. see Figure 8-7 on page 128.
Figure 8-5. PDU3 with Mounting Brackets Installed
CAUTION: Make sure the PDU3 is mounted so there is 50
mm clearance at the top and bottom of the unit to allow
for proper cooling.
