Chapter 6 - Module Installation

112 Adept Python Modules User’s Guide, Rev. E

Figure 6-4. Installing Axis 3 on Axis 2

4. Remove the shipping screws from Axis 2. See Figure 6-5.

Figure 6-5. Removing Shipping Screws from Axis 2

5. Remove the shipping screws from Axis 1. See Figure 6-6.
