adept technology Python User Manual

Chapter 3 - Python Linear Module Descriptions
46 Adept Python Modules User’s Guide, Rev. E
Figure 3-3. L12 Module without Brake, Shown at End of Stroke
Figure 3-4. L12 Module with Brake, Shown at End of Stroke
Figure 3-5. L08 Module with Brake (Left) and without Brake (Right)
137 mm
155 mm
243 mm
295.50 mm
Carriage shown at zero position in both drawings
