adept technology Python - Two-Axis Configuration Drawings

System Configuration and Module Types
Adept Python Modules User’s Guide, Rev. E 77
Figure 5-12. LT1 (Theta) Module User Flange Dimensions
240.00
2x Ø
63.00
62.80
8.90
13.00
A
Ø 50.00 B.C.
45°
3x 90°
4x M6 x 1.0 THRU
Ø
6.02
6.01
Ø
41.170
41.150
6.80
-A- ^J
25°
1.50
4.15
B
DETAIL A
SCALE 1:1
All dimensions
are in mm.
