Chapter 5 - Module System Descriptions
76 Adept Python Modules User’s Guide, Rev. E
Figure 5-10. LT1 (Theta) Module Envelope/Mounting Hole Dimensions (Side View)
Figure 5-11. LT1 (Theta) Module Envelope/Mounting Hole Dimensions (Bottom View)
31.50
65.00
45.50
51.05
38.50
98.00
6.00
Ø 6.50
OPTONAL CABLE
PASSAGE GROMMET
15.00
BOTH SIDES
2x M4 x 0.7
All dimensions
are in mm.
72.00
77.00
50.00
40.00
80.00
50.00
100.00
2x Ø
5.02
5.01
M5 SHCS - FAR SIDE
4x C'BORE FOR
Ø
6.02
6.01
M6 SHCS - FAR SIDE
4x C'BORE FOR
CL
SYM
All dimensions
are in mm.
