adept technology Python - PDU3 Connectors and Indicators

Typical AC Power Connection Diagrams for PDU3
Adept Python Modules User’s Guide, Rev. E 123
8.3 Typical AC Power Connection Diagrams for PDU3
Figure 8-2. Typical Single-Phase 200-240 VAC Connection
Figure 8-3. Typical Three-Phase 200-240 VAC Connection
Figure 8-4. Typical Three-Phase 380-415 VAC Connection
PE
PE
N
N
L
L
F4 10A
1Ø
200–240V~
20A
Adept PDU3
1Ø 100–240V~
Note: F4 is user-supplied, must be slow blow.
PE
PE
L3
L2
L2
L1
L1
3Ø
200–240V~
20A
200–240V~
Adept PDU3
1Ø 200–240V~
Note: F4 and F5 are user-supplied, must be slow blow.
F4
10A
F5 10A
PE
PE
N
L3
N
L2
L1
L1
3Ø
380–415V~
20A
380–415V~
200–240V~
Adept PDU3
1Ø 200–240V~
Note: F4 is user-supplied, must be slow blow.
F4 10A
