PDU3 Specifications
Adept Python Modules User’s Guide, Rev. E 129
8.9 PDU3 Specifications
Table 8-2. PDU3 Specifications
Input Power Requirements
Universal power input voltage 200-240 VAC (180-264 VAC max),
single phase
Power input frequency 50-60 Hz (47 - 63 Hz max)
Power input current 8 Amps
Power Input connector (mating) IEC 320 C13
Power Installation Category II Overvoltage
Amplifier DC Output
Output Voltage 24 VDC ±10%
Output Current 3 Amps maximum
a
a
Note: maximum combined amplifier DC output current and Aux/IO Blox output
current may not exceed 4 amps.
Hold up time 20 ms
AUX DC Output
Output Voltage 24 VDC +10% -15%
Output Current 3 Amps maximum
a
Hold up time 20 ms
Switched AC Output Section
Maximum Continuous Output Current 6 Amps
Output Voltage equal to input
Power Output Connector (mating) IEC 320 C14
Environmental
Ambient temperature 5° C to 40° C (41 to 104° F)
Humidity 5 to 90%, noncondensing
Pollution degree 2 (per IEC 1131-2/EN 61131-2)
Chassis protection class, unmounted IP-20 (NEMA Type 1)
Weight 2.2 kg
