adept technology Python - L-Series Module Types

Adept Python Modules User’s Guide, Rev. E 37
Python Linear Module
Descriptions 3
3.1 Adept Python Linear Modules
Use the Adept 3D Linear Modules Builder section of the Adept website (www.adept.com)
to select, configure, and request a quote for your linear modules. The website and this
chapter provide detailed information about Adept Python linear modules. See Chapter 4
for information about the Adept Python Theta modules.
Single-Axis and Multiple-Axis Configurations
You can order an Adept Python linear module system consisting of a single module,
MB-10 amplifier, and a SmartController CX. Or, multiple modules can be assembled into a
multi-axis system. For systems with an extended-reach Y-axis, or extended payloads, a
gantry support module is also available.
3.2 Linear Module Options
The following are configurable for each linear module:
• L-Series module type - L18, L12, and L08
• Stroke lengths - 100 and 200 mm increments standard
• Ball screw lead - 5, 10, and 20 mm leads standard
•Fail-safe brakes
• Motor mount orientation - in-line, side-, or bottom--mounted
• Harness exit configuration - left or right side
• Module preparation (assembly) - standard or cleanroom
