Chapter 5 - Module System Descriptions

80 Adept Python Modules User’s Guide, Rev. E

K Configuration

In the K configuration, the first axis is parallel to the work surface and rotated 90 degrees

so that the second axis is perpendicular to the work surface. The second axis’ slide

operates in a vertical ’Z’ motion (perpendicular to the work surface).

Available in the following configurations:

• K1200

• K2300

Figure 5-15. K1200 System

X-Axis

Motion

Z-Axis

Motion
