Linear Module Options
Adept Python Modules User’s Guide, Rev. E 57
L08 Module Options and Descriptor Number Key
The following charts show the module options unique to L08 modules (the ball screw type
options are the same for all module types).
Figure 3-20. L08 Descriptor Number Key, Part 1 of 2
L08 010 S10 B0
L08
010
020
030
040
050
060
080
S10
S20
B0
B2
MODULE SERIES
STROKE LENGTH
BALL SCREW TYPE
BRAKE OPTION
L08
100 mm
200 mm
300 mm
400 mm
500 mm
600 mm
800 mm
10 mm Lead
S05
5 mm Lead
20 mm Lead
No Brake
Motor Brake
