IO Blox
Adept Python Modules User’s Guide, Rev. E 105
Figure 5-49. Mounting onto an L18 Module
Figure 5-50. Mounting onto a Module T-Slot
IO Blox
Mounted
on L-18
Module
End Cap
IO Blox
Mounted
on Module
T-Slot
