Installing a Python Module System
Adept Python Modules User’s Guide, Rev. E 113
Figure 6-6. Removing Shipping Screws from Axis 1
6. Verify that all shipping screws have been removed, and that the system is free to
be lifted from the pallet.
7. Lift the system using a mechanical hoist or crane that is rated to handle the weight
of the system. Arrange a series of slings around the axes that will safely support
the system as it is being transported. See Figure 6-7 for an example.
Figure 6-7. Lifting a Python System Using a Hoist and Slings
CAUTION: The center of gravity in the Y-Axis is
dependent on the lengths and weights of the Y- and
Z-Axes. The module system may tilt abruptly as the
shipping screws are removed.
