Adept Python Modules User’s Guide, Rev. E 161

Advanced System

Configurations 12

12.1 Description

The installation drawing in Figure 12-1 on page 162 shows the cable connections for a

system with two 2-axis linear module robots running on one SmartController.

The installation drawing in Figure 12-2 on page 163 shows the cable connections for a

system with three 2-axis linear module robots and two PDUs running on one

SmartController.

The installation drawing in Figure 12-3 on page 164 shows the cable connections for a

system with three 2-axis linear module robots, two PDUs, and a Cobra s600 with Vision,

running on one SmartController.
