X Configuration
In the X configuration, the second axis' slide is mounted to the first axis' slide such that the
entire second axis operates in a back-and-forth Y motion (parallel to the work surface).
Available in the following configuration:
•X1100
Figure 5-16. X1100 System with Optional Mounting Feet
X-Axis
Motion
Y-Axis
Motion
Flyover Type
Cable Harness
