adept technology Python - Figure 1-1. L18 Linear Module with MB-10 Amplifier; Figure 1-2. L12 Linear Module with MB-10 Amplifier

Chapter 1 - Introduction
16 Adept Python Modules User’s Guide, Rev. E
Figure 1-1. L18 Linear Module with MB-10 Amplifier
Figure 1-2. L12 Linear Module with MB-10 Amplifier
L18 Module with
MotionBlox-10 Amp
185 mm
93 mm
L12 Module with
MotionBlox-10 Amp
125 mm
83 mm
