adept technology Python - G Configuration; Figure 5-14. G1200 System with Optional Mounting Feet

To Next Page

To Previous Page

System Configuration and Module Types

Adept Python Modules User’s Guide, Rev. E 79

G Configuration

In the G configuration, the second axis is rolled onto its side and mounted in a fixed

position on the first-axis' slide, so that the second axis' slide is perpendicular to the work

surface and moves in a horizontal motion.Available in the following configurations:

•G1100

• G1200

• G2300

Figure 5-14. G1200 System with Optional Mounting Feet

Rolling (Hi-Flex) Type

Cable Harness

X-Axis

Motion

Y-Axis

Motion
