Menu Descriptions
61179641L4-5B 5-61
NOTE
The Media Access Control (MAC) address is set at the factory.
Table 5-36. Static IP Settings - for IP over Ethernet Menu Options
Option Description Function
1 IP address This option is used to configure the IP address in
decimal dot format (i.e., ###.###.###.###).
2 Subnet mask This option is used to configure the subnet mask in
decimal dot format.
3 Default Gateway This option is used to configure the Default Gateway.
The Default Gateway is used to forward traffic to a
destination outside of the subnet of the Total Access
1248. The Default Gateway is configured in decimal dot
format.
4 TFTP IP address This option is used to configure the TFTP IP address.
The TFTP IP Address must be configured to use TFTP for
software upgrade. The TFTP address is configured in
decimal dot format.
5 TL1 Port Number (set >1023) This field is used to configure the Transaction Language
1 Port Number. The default TL1 Port Number is 13001,
however, it can be modified to any number greater than
1023.
6 TL1 IP Transport type This option is used to configure the TL1 IP Transport
Type. Each time the TL1 IP Transport type option is
selected, the setting is toggled between User Datagram
Protocol (UDP) and Transmission Control Protocol (TCP).
The default is TCP.
7 Reset IP Factory Defaults This option displays the “Restore IP Factory Defaults
Menu” on page 5-62.
