ADTRAN Total Access 1248 User Manual

Menu Descriptions
61179641L4-5B 5-45
Inband OAM Loopback Test Menu
Inband OAM Loopback Test
Main Menu\ATM Circuit Management\ATM OAM Settings\Inband OAM Loopback Test\
The Inband OAM Loopback Test menu (see Figure 5-27) is used to provision the Total Access
1248 OAM Loopback settings and to test the Inband channel PVC for an ATM fed box.
Figure 5-27. Inband OAM Loopback Test Menu
The Inband OAM Loopback Test menu options are shown in Table 5-26.
The Inband OAM Loopback Test menu fields are shown in Table 5-27.
Table 5-26. Inband OAM Loopback Test Menu Options
Option Description Function
1 Remote OAM Loopback
Location ID
This is option is used to enter the remote loopback
location ID. The remote loopback location ID is in
hexadecimal 16 byte format.
2 Type of OAM Loopback Cell This option is used to specify the type of OAM Loopback
cell. Options include the following:
•Segment
•End-to-End
3 Send Loopback Cell This option is used to send a loopback cell.
4 Reset Loopback Statistics This option clears the OAM loopback statistics for this
circuit.
5 Reset All Statistics This option clears all OAM loopback statistics.
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
Inband OAM Loopback Test
Port VPI VCI
0 0 32
Tx Loopback Request : 0 Rx OAM Cells : 0
Rx Loopback Request : 0 AIS State : FALSE
Tx Loopback Response : 0 RDI State : FALSE
Rx Loopback Response : 0
Loopback Passed : 0
Loopback Failed : 0
1. Remote OAM Loopback Location ID : FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
2. Type of OAM Loopback Cell : Segment
3. Send Loopback Cell
4. Reset Loopback Statistics
5. Reset All Statistics
Selection :
'?' - System Help Screen
