ADTRAN Total Access 1248 - Figure 5-106. Select Shelf Menu; Status Menu

Menu Descriptions
61179641L4-5B 5-157
Status Menu
Status
Main Menu\DSL Menus\Status\
NOTE
If expansion mode is enabled (refer to “Expansion Menu” on
page 5-90), the Select Shelf menu (see Figure 5-106) displays. A
host or client unit must be chosen in order to access the Status
menu.
Figure 5-106. Select Shelf Menu
The Status menu (see Figure 5-107) offers different options for ADSL status reporting.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (configured)
3. Client 2 (configured)
4. Client 3 (configured)
Selection :
'?' - System Help Screen
