ADTRAN Total Access 1248 - DSP Management Menu; Figure 5-102. Select Shelf Menu

Total Access 1248 Octal T1 IMA DSLAM Installation and Maintenance Practice
5-152 61179641L4-5B
DSP Management Menu
DSP Management Menu
Main Menu\DSL Menus\DSL Provisioning\ADSL Restore Menu\DSP Management Menu\
NOTE
If expansion mode is enabled (refer to “Expansion Menu” on
page 5-90), the Select Shelf menu (see Figure 5-102) displays. A
host or client unit must be chosen in order to access the DSP
Management menu.
Figure 5-102. Select Shelf Menu
The DSP Management menu (see Figure 5-103) provides options to reset all or individual
DSPs, and enable/disable the Auto Warm Start feature. Auto Warm Start resets the hardware
modules within the DSPs.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (not present)
3. Client 2 (not present)
4. Client 3 (not present)
Selection :
'?' - System Help Screen
