Menu Descriptions
61179641L4-5B 5-105
E1 Status Menu
E1 Status
Main Menu\Network Port\E1 Main Menu\E1 Status\
The E1 Status Menu (see Figure 5-69) displays the status of the E1 network circuits and a
summary of the associated alarm counts.
Figure 5-69. E1 Status Menu
The E1 Status menu options are shown in Table 5-71.
Table 5-71. E1 Status Menu Options
Option Field Function
N/A Framing This field displays the framing setting for the E1 circuit.
For more information, see Table 5-70 on page 5-104.
N/A Line Code This field displays the line code setting for the E1
circuit. For more information, see Table 5-70 on page 5-
104.
N/A E1 Alarm This field indicates if there are any E1 alarms.
N/A Total Alarms Red This field indicates the number of Loss of Signal (Red)
alarms.
N/A Total Alarms Yellow This field indicates the number of Receive Remote Alarm
Indication (Yellow) alarms.
N/A Total Alarms Blue This field indicates the number of Receive Alarm
Indication Signal (Blue) alarms.
8 Reset Alarm Counts This option is used to clear all the E1 status alarm
fields.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
E1 Status
1 2 3 4 5 6 7 8
Framing FAS+CRC FAS+CRC FAS+CRC FAS+CRC FAS+CRC FAS+CRC FAS+CRC FAS+CRC
Line Code HDB3 HDB3 HDB3 HDB3 HDB3 HDB3 HDB3 HDB3
E1 Alarm RED RED RED RED BLUE BLUE BLUE BLUE
Total Alarms
Red 2 2 2 2 0 0 0 0
Yellow 0 0 0 0 0 0 0 0
Blue 0 0 0 0 1 1 1 1
8. Reset Alarm Counts Cleared: 01/15/94 05:19:17
Selection :
