ADTRAN Total Access 1248 User Manual

Menu Descriptions
61179641L4-5B 5-123
IMA Group 1 Failure Monitoring Status Screen
IMA Group 1 Failur e Monitoring Status
Main Menu\Network Port\IMA Main Menu\Status/Failure Monitoring\IMA Group 1 Failure Monitoring Status\
The IMA Group 1 Failure Monitoring Status screen (see Figure 5-85) displays the status of the
group state and the Near End and
Far End failure status.
Figure 5-85. IMA Group 1 Failure Monitoring Status Screen
The IMA Group 1 Failure Monitoring Status screen fields are shown in Table 5-87.
Table 5-87. IMA Group 1 Failure Monitoring Status Screen Fields
Field Description
NE Group State This field displays the Near End group status.
FE Group State This field displays the Far End group status.
NE Failure Status This field displays the Near End failure status.
FE Failure Status This field displays the Far End failure status.
Link With Least Delay This field displays the link with the least delay.
Max Link Differential Delay This field displays the maximum link differential delay.
Configured TX Links This field displays the number of transmitting links that are
configured.
Active Tx Links This field displays the number of transmitting links that are
active.
Configured RX Links This field displays the number of receiving links that are
configured.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA Group 1 Failure Monitoring Status
NE Group State : Operational
FE Group State : Operational
NE Failure Status : No Failure
FE Failure Status : No Failure
Link With Least Delay : 1
Max Link Differential Delay : 0
Configured TX Links : 8
Active Tx Links : 8
Configured RX Links : 8
Active Rx Links : 8
FE Failure Data : Unavailable
FE Frame Length : 32
Group Version : Unknown
Timing Source : Port 1
Last Timing Source Change : MM/DD/YY HH:MM:SS
