Menu Descriptions
61179641L4-5B 5-117
IMA Group Provisioning Menu
IMA Group Provisioning
Main Menu\Network Port\IMA Main Menu\IMA Provisioning\IMA Group Provisioning\
The IMA Group Provisioning menu (see Figure 5-80) is used to provision the IMA Group. An
IMA Group is a collection of physical links bundled together.
NOTE
The IMA Group must be Out of Service-Unassigned in order to
change the provisioning options.
Figure 5-80. IMA Group Provisioning Menu
The IMA Group Provisioning menu options are shown in Table 5-82.
Table 5-82. IMA Group Provisioning Menu Options
Option Description Function
1 Group Operation Mode The IMA Group must be Out of Service-Unassigned in
order to change the options. If the IMA Group is In
Service or Out of Service-Maintenance, only the Group
Operation Mode is available for changes.
The Group Operation Mode settings are as follows:
• Out of Service-Unassigned
• Out of Service-Maintenance
• In Service
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA Group Provisioning
1. Group Operation Mode OOS - Unassigned
2. IMA Transmit ID (0-255) 101
3. IMA TX Frame Length 128
4. Min. TX Active Links 1
5. Min. RX Active Links 1
6. Max. Link Diff. Delay (0-100) 100
7. Group Version Version 1.1
Selection :
'?' - System Help Screen
To Next Page
