Total Access 1248 Octal T1 IMA DSLAM Installation and Maintenance Practice
5-164 61179641L4-5B
Performance Menu
Performance Menu
Main Menu\DSL Menus\Performance Menu\
NOTE
If expansion mode is enabled (refer to “Expansion Menu” on
page 5-90), the Select Shelf menu (see Figure 5-114) displays. A
host or client unit must be chosen in order to access the
Performance menu.
Figure 5-114. Select Shelf Menu
The Total Access 1248 provides displays to help analyze performance of the system. This
information is available in displays of 15-minute and daily intervals. Figure 5-115 displays the
Performance menu options.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (configured)
3. Client 2 (configured)
4. Client 3 (configured)
Selection :
'?' - System Help Screen
To Next Page
