ADTRAN Total Access 1248 User Manual

Menu Descriptions
61179641L4-5B 5-129
IMA Loopback Menu
IMA Loopback
Main Menu\Network Port\IMA Main Menu\IMA Loopback\
The IMA Loopback menu (see Figure 5-87) is used to initiate loopbacks for testing the IMA
group. Each IMA Loopback menu option can be enabled or disabled.
Figure 5-87. IMA Loopback Menu
The IMA Loopback menu options are shown in Table 5-89.
Table 5-89. IMA Loopback Menu Options
Option Description Function
1 Data Lpbk Towards Network This option when enabled is used to perform a data
loopback toward the network.
2 ATM Lpbk Towards Network This option when enabled is used to perform an ATM
loopback toward the network.
3 ATM Lpbk Towards Customer This option when enabled is used to perform an ATM
loopback toward the customer.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA Loopback Menu
1. Data Lpbk Towards Network DISABLED
2. ATM Lpbk Towards Network DISABLED
3. ATM Lpbk Towards Customer DISABLED
Selection :
'?' - System Help Screen
