Total Access 1248 Octal T1 IMA DSLAM Installation and Maintenance Practice
5-90 61179641L4-5B
Expansion Menu
Expansion
Main Menu\System Management\Expansion\
The Expansion Menu (see Figure 5-58) is used to enable or disable expansion capabilities for
up to four Total Access 1248 units (one host and three clients). The expansion mode can only
be enabled on the host units.
Figure 5-58. Expansion Menu
The Expansion Menu options are shown in Table 5-58. The Expansion Menu fields are shown
in Table 5-59.
Table 5-58. Expansion Menu Options
Option Description Function
1 Mode This option is used to designate Enabled (Host) or
Disabled.
2 Clear Packet Counts This option is used to clear all packet counts.
Table 5-59. Expansion Menu Fields
Field Description
Maintenance Packets This field displays the number of packets that have been
transmitted and received.
Expansion Out Link This displays the status of the expansion link.
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
Expansion Menu
1. Mode Enabled (Host)
2. Clear Packet Counts
Selection :
Maintenance Packets:(TX/RX) 0/0
Expansion Out Link: DOWN
'?' - System Help Screen
To Next Page
