Current ATM OAM Statistics Menu
Current ATM OAM Statistics
Main Menu\ATM Circuit Management\PVC/PVP Management\Current ATM OAM Statistics\
The Current ATM Operations and Maintenance (OAM) Statistics menu (see Figure 5-15)
displays the network and line side OAM information for each ATM circuit.
OAM is the group of network management functions that provide network fault indication and
performance information.
Figure 5-15. Current ATM OAM Statistics Menu
The Current ATM OAM Statistics menu options are shown in Table 5-11.
Table 5-11. Current ATM OAM Statistics Menu Options
Option Description Function
1 OAM Loopback Test Screen This option displays the “OAM Loopback Test Menu” on
page 5-28.
2 Clear Current PVC OAM Stats This option clears the currently displayed PVC OAM
statistics.
3 Clear All PVC OAM Stats This option clears all PVCs OAM statistics.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Current ATM OAM Statistics
Endpoint 1 Endpoint 2 Modem Status
Port VPI VCI Port VPI VCI Down
0 35 1000 1 0 35
Endpoint 1 (Net --> Cust) Endpoint 2 (Net <-- Cust)
Rx OAM Cells : 0 Rx OAM Cells : 0
AIS State : FALSE AIS State : FALSE
RDI State : FALSE RDI State : FALSE
1. OAM Loopback Test Screen
2. Clear Current PVC OAM Stats
3. Clear All PVC OAM Stats
Selection :
'N' - Next PVC 'P' - Previous PVC 'S' - Select PVC
