ADTRAN Total Access 1248 User Manual

Menu Descriptions
61179641L4-5B 5-139
Figure 5-95 displays an example of the Edit ADSL Profiles menu.
NOTE
The Custom Name reference indicates the user assigned profile
name.
Figure 5-95. Edit ADSL Profile Menu
The Edit ADSL line options are defined in Table 5-98.
Table 5-98. Edit ADSL Profile Menu Options
Option Description Function Settings Default
1 State This option is used to assign a
state to the profile.
Active; Inactive Inactive
2 Host This option is used to assign a
port to the profile for the host
unit.
1-48 None
3 Client 1 This option is used to assign a
port to a profile for the first
client unit, if enabled.
1-48 None
4 Client 2 This option is used to assign a
port to a profile for the second
client unit, if enabled.
1-48 None
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
Profile Settings for: Custom Name
1. State: Inactive
2. Host : None
3. Client 1 : (Not Present) None
4. Client 2 : (Not Present) None
5. Client 3 : (Not Present) None
6. Rate Mode: Rate Adaptive 7. Line Type: Fast
Downstream
Upstream
8. Target SNR Margin 6 dB 16. Target SNR Margin 6 dB
9. Max SNR Margin 9 dB 17. Max SNR Margin 9 dB
10. Min SNR Margin 0 dB 18. Min SNR Margin 0 dB
11. Fast Max Tx Rate 8160 kbps 19. Fast Max Tx Rate 896 kbps
12. Fast Min Tx Rate 32 kbps 20. Fast Min Tx Rate 32 kbps
13. Interleave Max Tx Rate N/A 21. Interleave Max Tx Rate N/A
14. Interleave Min Tx Rate N/A 22. Interleave Min Tx Rate N/A
15. Interleave Max Delay N/A 23. Interleave Max Delay N/A
Selection :
NOTE: Changes will only be saved when profile changes states!
'?' - System Help Screen
