ADTRAN Total Access 1248 User Manual

Menu Descriptions
61179641L4-5B 5-27
The Current ATM OAM Statistics menu fields are shown in Table 5-12.
Table 5-12. Current ATM OAM Statistics Menu Fields
Field Description
Endpoint 1
Rx OAM Cells This field displays the total number of received OAM cells for
Endpoint 1.
AIS State This field indicates if the Endpoint is in AIS state (True) or not
(False).
RDI State This field indicates if the Endpoint is in the RDI state (True) or
not (False).
Endpoint 2
Rx OAM Cells This field displays the total number of received OAM cells for
Endpoint 2.
AIS State This field indicates if the Endpoint is in AIS state (True) or not
(False).
RDI State This field indicates if the Endpoint is in the RDI state (True) or
not (False).
