Menu Descriptions
61179641L4-5B 5-109
E1 Test Menu
E1 Test
Main Menu\Network Port\E1 Main Menu\E1 Test\
Figure 5-72 shows the E1 Test Menu.
Figure 5-72. E1 Test Menu
The E1 Test Menu options are shown in Table 5-75.
Table 5-75. E1 Test Menu Options
Option Definition Function
1 Payload Loopback This option is used to select a payload loopback test.
2 Line Loopback This option is used to select a line loopback test.
3 Local Loopback This option is used to select a local loopback test.
4 No Loopback This option is used to deselect a loopback test or to
indicate no loopback is specified.
5 Clear E1 Loopbacks On All
Ports
This option clears all loopbacks without further
prompting.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
E1 Test Menu for Port # 1 - No Loopback
1. Payload Loopback
2. Line Loopback
3. Local Loopback
4. No Loopback
5. Clear E1 Loopbacks On All Ports
'N' - Next E1 Port 'P' - Previous E1 Port
Selection :
'?' - System Help Screen
