Total Access 1248 Octal T1 IMA DSLAM Installation and Maintenance Practice
5-100 61179641L4-5B
The T1 Performance Monitoring Status screen hot keys are defined in Table 5-66.
CV-P Code Violations This code indicates an occurrence of either a CRC-6
error or frame bit error on the path.
CV-L Code Violations This code indicates an occurrence of either a CRC-6
error or frame bit error on the line.
ES-L Errored Seconds This code indicates seconds with either a bipolar
violation or a CRC-6 error on the line.
Table 5-66. T1 Performance Monitoring Status Screen Hot Keys
Hot Key Description Function
B
Backward(2hrs/15min PM) This hot key is used to display performance monitoring
statistics for the last 2 hours, in 15 minute intervals.
C
Clear PM Stats This hot key is used to clear the performance monitoring
statistics.
F
Forward(2hrs/15min PM) This hot key is used to display performance monitoring
statistics for the next 2 hours, in 15 minute intervals.
N
Next Port This hot key is used to display the next port.
P
Previous Port This hot key is used to display the previous port.
S
Select Port This hot key is used to select a specific port.
Table 5-65. T1 Performance Monitoring Status Screen Codes (Continued)
Code Definition Description
