Menu Descriptions
61179641L4-5B 5-101
T1 Test Menu
T1 Test
Main Menu\Network Port\T1 Main Menu\T1 Test\
Figure 5-65 shows the T1 Test Menu.
Figure 5-65. T1 Test Menu
The T1 Test Menu options are shown in Table 5-67.
Table 5-67. T1 Test Menu Options
Option Definition Function
1 Payload Loopback This option is used to select a payload loopback test.
2 Line Loopback This option is used to select a line loopback test.
3 Local Loopback This option is used to select a local loopback test.
4 No Loopback This option is used to deselect a loopback test or to
indicate no loopback is specified.
5 Clear T1 Loopbacks On All
Ports
This option clears all T1 loopbacks on all ports without
further prompting.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
T1 Test Menu for Port # 1 - No Loopback
1. Payload Loopback
2. Line Loopback
3. Local Loopback
4. No Loopback
5. Clear T1 Loopbacks On All Ports
'N' - Next T1 Port 'P' - Previous T1 Port
Selection :
'?' - System Help Screen
