Advantech-DLoG DLT-V8310 - Fig. 14.7: Dimensions DLT-V8312 Top View

To Next Page

To Previous Page

Technical data

Page 148 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG

DLT-V8312 Top view

Dimensions without add-ons (in mm)

Example:

Fig. 14.7: Dimensions DLT-V8312 top view

The installation depth of the devices varies depending on the type of touchscreen:

Device type Building depth (side view)

DLT-V8312 standard resistive touchscreen 93.5 mm (see figure)

DLT-V8312 sunlight readable resistive

touchscreen

95.1 mm

DLT-V8312 PCT touchscreen 96.4 mm
