Mounting (mechanical and electrical)
Advantech-DLoG DLT-V83 Series Manual V1.31 Page 69 of 178
7. Mounting (mechanical and electrical)
Information in this chapter:
7.1 Warning about injuries and physical damage
7.2 Overview of mounting steps
7.3 Suitable mounting position
7.4 Connecting external accessories to the DLT-V83
7.5 Attaching the device mounting bracket (optional)
7.6 Connecting DC devices to the power supply
7.7 Connecting AC devices to the power supply
7.8 Attaching the cable cover
WARNING
Hazardous voltage, electric shock from contact with live parts.
The following mounting information is intended for qualified skilled personnel.
Only electronic and mechanical skilled personnel are permitted to install DLT-
V83 industrial PCs.
Moreover, specialized knowledge about lithium-ion batteries and the applicable
safety regulations is also required for devices with internal UPS (optional).
