Page 96 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG
8.2.4. Measurement results of the power consumption
According to ErP
Test results
Idle Mode 24.22 W
Sleep Mode 0.91 W
Soft-Off-Mode (S5) 0.91 W
Lowest Power State 0,00 W (with special connection cable)
Total Energy Consumption (ETEC) 90.07
Test conditions
Required Actual
Input voltage 230 (±1 %) V a.c. 229.82 – 230.05 V
THD < 2 % < 2 %
Frequency 50 Hz (±1 %) 5 0 Hz
Ambient temperature
(23 ±5) °C
23.3ºC
Ambient humidity 10 to 80 % 31 %RH
Ambient light (250 ±50) Lux / (no automatic display
luminance control
Power analyzer used N4L type PPA1530
(SIQ ID 503; Calibration valid till 2015-07-01)
8.2.5. Special connection cable for AC device
To facilitate achieving the lower power state:
 Set the switch of the Advantech-DLoG power supply cable to Off.
