Advantech-DLoG DLT-V8310 - Connections, Expansion Interfaces; Fig. 8.6: AC Device External Connections, Detail View

To Next Page

To Previous Page

Power supply units, pin assignment, power supply

Advantech-DLoG DLT-V83 Series Manual V1.31 Page 97 of 178

8.2.6. Connections, expansion interfaces

Fig. 8.6: AC device external connections, detail view

Pin assignment (default)

Power supply 100 to 240 VAC

Audio MIC PWR out Voice kit

COM1, COM2 Serial interfaces

2 x RSMA (optional) Remote WiFi antenna(s)

RJ45 LAN Ethernet 10/100/1000 Mbps

USB2, USB1, USB0 USB 2.0 interfaces (HI-SPEED™), bootable

Expansion interfaces package 1 (optional)

D I/O Digital I/O

RJ45 LAN Ethernet 10/100/1000 Mbps

Expansion interfaces package 1 (optional)

CAN CAN interface

D I/O Digital I/O

RJ45 LAN Ethernet 10/100/1000 Mbps
