Operating the touchscreen, front keys
Advantech-DLoG DLT-V83 Series Manual V1.31 Page 33 of 178
5.2. Operating the touchscreen
Depending on the device version, the DLT-V83 is equipped with a resistive touchscreen
or a projected-capacitive touchscreen with continuous glass front (abbreviated PCT).
Resistive touchscreen available for PCT available for
DLT-V8310 with 5 or 26 front keys
DLT-V8312 with 5 or 26 front keys
DLT-V8315 with 5 or 26 front keys
DLT-V8310 with 9 front keys
DLT-V8312 with 9 front keys
DLT-V8315 with 9 front keys
TIP: Use touchscreen protective film
Optional protective film is available for the touchscreens.
Details in 10.20 Protective film for touchscreen (optional).
5.2.1. Prevent damage to the touchscreen
Information valid for all touchscreen types, resistive and PCT!
Keep the touchscreen clean.
To not touch the touchscreen with pointed, sharp, rough or hard objects, e.g. ball
point pens, writing implements, tools of any kind (e.g. screwdrivers).
Prevent any kind of adhesive applied on the surface.
Ensure that the screen surface is not influenced by high voltages or static
electricity.
Do not use excessive force when touching touchscreens, do not hit or press hard.
Do not put the device down with the touchscreen facing down, if necessary, place a
clean cloth underneath.
5.2.2. Operating the resistive touchscreen
Operate the resistive touchscreen with:
− Clean, dry fingers.
− Clean, dry, soft gloves.
− Suitable touch stylus (plastic or wood, rounded tip).
