Technical data

Advantech-DLoG DLT-V83 Series Manual V1.31 Page 151 of 178

Top view

Dimensions without add-ons (in mm)

Example:

Fig. 14.10: Dimensions DLT-V8315 top view (standard resisitive touchscreen)

The installation depth of the devices varies depending on the type of touchscreen:

Device type Building depth (side view)

DLT-V8315 standard resisitive touchscreen 98 mm (see figure)

DLT-V8315 PCT touchscreen 97 mm
