Advantech EKI-7428G Series User Manual

MANAGING SWITCH
109
The ensuing table for LLDP Global Config settings are informational only: LLDP Enabled,
LLDP PDU Disable Action, Transmission Interval, Holdtime Multiplier, Reinitialization Delay
and Transmit Delay.
LLDP Port Settings
The LLDP Port Settings page allows you to configure the state (enabled or disabled) of the
selected port.
To access this page, click Management > LLDP > LLDP Port Settings.
Figure 4-81. Management > LLDP > LLDP Port Settings > LLDP Port Configuration
The following table describes the items in the previous figure.
Table 4-79. Management > LLDP > LLDP Port Settings > LLDP Port Configuration
Item Description
Port Select Enter the port number associated with the LLDP setting.
State Click the drop-down menu to select the LLDP port state.
Apply Click Apply to save the values and update the screen.
