MANAGING SWITCH
64
MLD Static Group
The MLD Static Group page allows you to configure specified ports as static member ports.
To access this page, click L2 Switching > Multicast > MLD Snooping > MLD Static
Group.
Figure 4-36. L2 Switching > Multicast > MLD Snooping > MLD Static Group
The following table describes the items in the previous figure.
The ensuing table for MLD Static Groups Status settings are informational only: VLAN ID,
Group IP Address, Member Ports and Modify.
Multicast Groups
To access this page, click L2 Switching > Multicast > MLD Snooping > Multicast
Groups.
The ensuing table for Multicast Groups settings are informational only: ID, Group IP
Address, Member Ports, Type and Life (Sec).
Router Ports
To access this page, click L2 Switching > Multicast > MLD Snooping > Router Ports.
The ensuing table for Router Ports settings are informational only: VLAN ID, Port and
Expiry Time (Sec).
Table 4-34. L2 Switching > Multicast > MLD Snooping > MLD Static Group
Item Description
VLAN ID Enter the VLAN ID to define the local MLD Static Group.
Group IP Address Enter the IP address associated with the static group.
Member Ports Enter the ports designated with the static group.
Add Click Add to add a MLD static group.
