MANAGING SWITCH
63
The ensuing table for MLD Snooping Information settings are informational only: MLD
Snooping State, MLD Snooping Version and MLD Snooping V2 Report Suppression.
The ensuing table for MLD Snooping Table settings are informational only: Entry No.,
VLAN ID, MLD Snooping Operation State, Router Ports Auto Learn, Query Robustness,
Query Interval (sec.), Query Max Response Interval (sec.), Last Member Query count, Last
Member Query Interval (sec), Immediate Leave and Edit (click to modify the settings).
MLD Querier
The MLD Querier page allows you to select and enable/disable the MLD querier and define
the version (IGMPv1 or IGMPv2) when enabled.
To access this page, click L2 Switching > Multicast > MLD Snooping > MLD Querier.
Figure 4-35. L2 Switching > Multicast > MLD Snooping > MLD Querier
The following table describes the items in the previous figure.
The ensuing table for MLD Querier Status settings are informational only: VLAN ID,
Querier State, Querier Status, Querier Version and Querier IP.
MLD Snooping
Report Suppression
Select Enable or Disable to designate the status of the report suppression.
Apply Click Apply to save the values and update the screen.
Table 4-33. L2 Switching > Multicast > MLD Snooping > MLD Querier
Item Description
VLAN ID Enter the VLAN ID to configure.
Querier State Select Enable or Disable status on the selected VLAN.
Enable: Enable IGMP Querier Election.
Disable: Disable IGMP Querier Election.
Querier Version Select the querier version (IGMPV1 or IGMPV2) designated to the MLD
Querier function.
Apply Click Apply to save the values and update the screen.
Table 4-32. L2 Switching > Multicast > MLD Snooping > MLD Settings (Continued)
Item Description
