R3131 Spectrum Analyzer Operation Manual
Preface-1
PREFACE
This manual provides the information necessary to check functionality, operate and program the R3131 Spectrum
Analyzer. Be sure to read this manual carefully in order to use the spectrum analyzer safely.
•
Organization of this manual
This manual consists of the following chapters:
1. Introduction
• Product Description
• Standard Accessories and Power Cable Options
• Operating Environment
• Operation Check
• Cleaning, Storing and Transporting
Includes a description of the spec-
trum analyzer and its’ parts along
with information on its’ operating
environment and how to perform a
system checkout.
2. Operation
• Controls and Connectors on the Front and Rear
Panels
• Screen Annotation
• Basic Operation
• Measurement Examples
Describes the names and the func-
tions of each part on the panels. You
can learn the basic operation of the
spectrum analyzer through the exam-
ples shown in this chapter.
3. Reference
• Menu Index
• Menu Map
• Functional Description
Shows a list of operation keys, and
describes the function of each key.
4. Remote Control
•GPIB
•RS-232
Gives an outline of the GPIB and
RS-232 interfaces, and how to con-
nect and set them up. Also included
are a list of commands necessary for
programming and using the program
examples.
5. Specifications Shows the specifications of the spec-
trum analyzer.
APPENDIX 1. Error Messages If an error occurs during operation,
an error number and its correspond-
ing error message are displayed. The
meaning of each error is explained in
this section.
APPENDIX 2. Glossary Terminology related to the spectrum
analyzer is explained in this section.
