ACCEPTANCE TESTING
7-5
Recommended test equipment
The test equipment recommended for acceptance testing is shown below. Alternative equipment
may be used provided it complies with the stated minimum specification.
Recommended test equipment
Description Minimum specification Example
Power meter
±0.1 dB from 9 kHz to 2.51 GHz
Aeroflex 6960B
with 6912 and
6932 sensors #
Measuring receiver
0 dBm to −127 dBm; 2.5 MHz to 2.51 GHz.
Capable of measuring residual FM <2 Hz and SSB
phase noise <−124 dBc/Hz at 20 kHz offset from a
470 MHz carrier
Agilent 8902A with
Option 037 * and
11722A sensor and
11793A down
converter ##
Low noise signal
generator
+8 dBm from 32.5 MHz to 2.54 GHz
SSB phase noise <−127 dBc/Hz at 20 kHz offset
from a 470 MHz carrier
Aeroflex 2041
Frequency counter 10 Hz to 2.51 GHz Agilent 53181A
with option 030
Audio analyzer Capable of measuring THD of 0.01% from 100 Hz
to 20 kHz
Rohde & Schwarz
UPA3
Spectrum analyzer DC to 7.53 GHz, 3 Hz resolution bandwidth Anritsu MS2602A
Modulation meter
AM, FM and ΦM 50 kHz to 2.32 GHz, accuracy
±1% at 1 kHz modulation frequency.
Aeroflex 2305 plus
distortion option **
Function generator
DC to 100 kHz sine, ±0.6 dB flatness, 100 kHz
square wave
Agilent 3325B
Digital voltmeter DC voltage measurement Solartron 7150+
50 Ω load
(termination)
1 W, 50 Ω nominal impedance, DC to 2.51 GHz
Lucas Weinschel
M1404N
2 turn loop 25 mm diameter
Oscilloscope 100 MHz bandwidth Tektronix TAS 465
* Option 037 is necessary to measure SSB phase noise.
# The 6932 sensor is required only when testing instruments fitted with Option 3 (high power).
## If the receiver and down converter are not available, an alternative procedure to ensure
attenuator pad accuracy using a power meter is given.
** The distortion option of the 2305 Modulation Meter allows modulation distortion tests to be
carried out with greater ease. If a 2305 with the distortion option is not available, the audio
analyzer may be connected to the modulation meter LF output and set to measure distortion.
