DETAILED OPERATION
4-33
Default settings
The instrument is reset to the factory default settings in the following cases:
• At power-up.
• Following execution of the RCL 999 command.
• Following execution of the
*
RST command.
The default settings are shown in Table 4-1.
Table 4-1 Instrument default settings
Carrier frequency :
Step :
(Maximum available) 1.2 GHz/2.05 GHz/2.51 GHz
1 kHz
RF level
Step :
-140 dBm (or -2 dBm with the No Attenuator option)
1 dB Status: ON
Modulation mode Internal FM, modulation disabled
Modulations : FM1 : Deviation: 0 Hz, OFF
: Internal source, frequency: 1 kHz, sine
FM2 : Deviation: 0 Hz, OFF
: Internal source, frequency: 400 Hz, sine
ΦM1 : Deviation: 0 rad, OFF
: Internal source, frequency: 1 kHz, sine
ΦM2 : Deviation: 0 rad, OFF
: Internal source, frequency: 400 Hz, sine
AM1 : Deviation: 0%, OFF
: Internal source, frequency: 1 kHz, sine
AM2 : Deviation: 0%, OFF
: Internal source, frequency: 400 Hz, sine
Pulse : OFF
SINAD : OFF
Modulation steps :
ΔFM 1 kHz, ΔΦM 0.1 rad, ΔAM 1%
Mod frequency steps : 10 Hz
Carrier sweep
Freq mode :
Mode :
Type:
Ext trigger :
Start :
Stop :
Step size :
Time :
SINAD
Averages:
Weighting filter:
Fixed
Single sweep
Linear
Off
9 kHz
(Maximum available)
1 kHz
50 ms
5
CMESS
