OPTION 11 FAST PULSE AND HIGH POWER
Annex-B-8
(1) Perform AUTO ZERO and AUTO CAL on the power meter.
(2) Connect the test equipment as shown in Fig. B-5.
(3) On the UUT set:
[CARR FREQ] 30 [kHz]
[RF LEVEL] −4 [dB]
(4) Record the output level measured by the power meter against each of the carrier frequencies
shown in Table B-1, checking that the results are within specification.
(5) Set the UUT RF level to +7 dBm and repeat (4) using Table B-2.
(6) Set the UUT RF level to +25 dBm and repeat (4) using Table B-3, decreasing the RF level to
+19 dBm when testing at carrier frequencies above 1.2 GHz and further decreasing the RF
level to +14 dBm when testing at carrier frequencies above 2.4 GHz.
ALC linearity
Test procedure
(1) Perform AUTO ZERO and AUTO CAL on the power meter.
(2) Connect the test equipment as shown in Fig. B-5.
(3) On the UUT set:
[CARR FREQ] 2.5 [MHz]
[RF LEVEL] −4 [dB]
(4) Record the output level measured by the power meter against each of the steps shown in
Table B-4, checking that the results are within specification.
(5) Set the UUT carrier frequency to 950 MHz and repeat (4) using Table B-5.
(6) Set the UUT carrier frequency to 2050 MHz and repeat (4) using Table B-6.
(7) Set the UUT carrier frequency to 2510 and repeat (4) using Table B-7.
Carrier harmonics
Specification
As the standard instrument below +7 dBm.
Harmonics:
Typically better than −25 dBc for RF levels up to 6 dB below the
maximum specified output
Test equipment
Description Minimum specification Example
Spectrum
analyzer
DC to 7.6 GHz frequency coverage Anritsu MS2602A
