ACCEPTANCE TESTING
7-48
Table 7-10 Attenuator test at 1199 MHz
RF Level (dBm) RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
0
−0.8
_______ +0.8
−4.1 −4.9
_______
−3.3
−15.1 −15.9
_______
−14.3
−26.1 −26.9
_______
−25.3
−37.1 −37.9
_______
−36.3
−48.1 −48.9
_______
−47.3
−59.1 −59.9
_______
−58.3
−70.1 −70.9
_______
−69.3
−81.1 −81.9
_______
−80.3
−92.1 −92.9
_______
−91.3
−103.1 −103.9
_______
−102.3
Table 7-11 Attenuator test at 1875 MHz (2023B and 2025)
RF level (dBm) RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
0
−1.2
_______ +1.2
−4.1 −5.3
_______
−2.9
−15.1 −16.3
_______
−13.9
−26.1 −27.3
_______
−24.9
−37.1 −38.3
_______
−35.9
−48.1 −49.3
_______
−46.9
−59.1 −60.3
_______
−57.9
−70.1 −71.3
_______
−68.9
−81.1 −82.3
_______
−79.9
−92.1 −93.3
_______
−90.9
−103.1 −104.5
_______
−101.7
