ACCEPTANCE TESTING
7-71
Table 7-51 ALC linearity at 2510 MHz
RF level (dBm) RF Level Min.
(dBm)
Result (dBm) RF Level Max.
(dBm)
−4 −5.6
_______
−2.4
−3 −4.6
_______
−1.4
−2 −3.6
_______
−0.4
−1 −2.6
_______ +0.6
0
−1.6
_______ +1.6
1
−0.6
_______ +2.6
2 0.4 _______ +3.6
3 +1.4 _______ +4.6
4 +2.4 _______ +5.6
5 +3.4 _______ +6.6
6 +4.4 _______ +7.6
7 +5 _______ +9
8 +6 _______ +10
9 +7 _______ +11
10 +8 _______ +12
11 +9 _______ +13
12 +10 _______ +14
12.1 +10.1 _______ +14.1
12.2 +10.2 _______ +14.2
12.3 +10.3 _______ +14.3
12.4 +10.4 _______ +14.4
12.5 +10.5 _______ +14.5
12.6 +10.6 _______ +14.6
12.7 +10.7 _______ +14.7
12.8 +10.8 _______ +14.8
12.9 +10.9 _______ +14.9
13 +11 _______ +15
14 +12 _______ +16
