ACCEPTANCE TESTING

7-74

Table 7-54 Carrier harmonic tests at +13 dBm

Carrier

frequency (MHz)

2nd harmonic

max. level

(dBc)

Result (dBc) 3rd harmonic

max. level

(dBc)

Result (dBc)

0.01

−25

_______

−25

_______

0.1

−25

_______

−25

_______

1

−25

_______

−25

_______

9.9

−25

_______

−25

_______

12.1

−25

_______

−25

_______

18.7

−25

_______

−25

_______

18.8

−25

_______

−25

_______

37.4

−25

_______

−25

_______

37.6

−25

_______

−25

_______

74.9

−25

_______

−25

_______

75.1

−25

_______

−25

_______

150

−25

_______

−25

_______

151

−25

_______

−25

_______

299

−25

_______

−25

_______

301

−25

_______

−25

_______

599

−25

_______

−25

_______

601

−25

_______

−25

_______

750

−25

_______

−25

_______

950

−25

_______

−25

_______

1199

−25

_______

−25

_______

2023B and 2025

1201

−25

_______

−25

_______

1501

−25

_______

−25

_______

1900

−25

_______

−25

_______

2025 ONLY

2510

−25

_______

−25

_______
