OPTION 11 FAST PULSE AND HIGH POWER
Annex-B-15
Table B-3 RF output at +25 dBm
Carrier frequency
(MHz)
RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
0.03 +23.5 _______ +26.5
0.33 +23.5 _______ +26.5
1 +23.5 _______ +26.5
9 +23.5 _______ +26.5
11 +23.5 _______ +26.5
60 +23.5 _______ +26.5
180 +23.5 _______ +26.5
300 +23.5 _______ +26.5
420 +23.5 _______ +26.5
540 +23.5 _______ +26.5
660 +23.5 _______ +26.5
780 +23.5 _______ +26.5
900 +23.5 _______ +26.5
1020 +23.5 _______ +26.5
1140 +23.5 _______ +26.5
1200 +23.5 _______ +26.5
2023B and 2025, +19 dBm
1201 +17 _______ +21
1260 +17 _______ +21
1380 +17 _______ +21
1500 +17 _______ +21
1620 +17 _______ +21
1740 +17 _______ +21
1860 +17 _______ +21
1980 +17 _______ +21
2025 ONLY, +19 dBm
2220 +17 _______ +21
2340 +17 _______ +21
2400 +17 _______ +21
+14 dBm
2401 +12 _______ +16
2510 +12 _______ +16
